The new Luxman L-505Z inherits all the high-quality sound know-how from the higher-end models It achieves even more versatility as an integrated amplifier. Redefining the standard and now reaching new heights. The L-505Z invites you to the exciting world of high-end
audio.
The new L-505Z includes many of the features of the L-507Z and L-509Z, including the LECUA volume control and L.I.F.E.S 1.0 audio circuit and MM and MC phono stage, dual headphone outputs and more.
The Luxman is very transparent, allowing you to get close to the moment the recording was done, being in the room with the musician, getting intimate with the effortless detail, especially micro-detail. Muscular when it needs to be, bringing the scale of instruments into focus. Tight bass, never forceful, just lively, bringing the launch of a sudden pressure wave of air as a drum is struck into your room as if you were present the day the recording was done.
Luxman's L-505 Z is not an inexpensive amplifier, but it is the first rung on the Luxman amp ladder – and yet it didn't sound anything like an entry point amp. Made entirely in Japan, the elegant L-505 Z features superb Swiss-watch build quality and sound quality to match.
Specifications:
| Rated output |
100W + 100W (8Ω),
150W + 150W (4Ω) |
Input sensitivity/
input impedance |
PHONO (MM): 2.5mV/47kΩ
PHONO (MC): 0.3mV/100Ω
LINE: 180mV/47kΩ
BAL.LINE: 180mV/55kΩ
MAIN IN: 1V/47kΩ |
| Output voltage |
PRE OUT: 1V |
| Frequency response |
PHONO: 20Hz to 20kHz (±0.5dB)
LINE: 20Hz to 100kHz (within -3dB) |
| Total harmonic distortion |
0.009% or less (8Ω, 1kHz)
0.09% or less (8Ω, 20Hz to 20kHz) |
| S/N ratio (IHF-A) |
PHONO (MM): 87dB or more
PHONO (MC): 70dB or more
LINE: 104dB or more |
| Volume adjustment |
LECUA |
| Amplification feedback circuit |
LIFES 1.0 |
| Output configuration |
Bipolar parallel push-pull |
| Damping factor |
200 |
| Max. amount of tone control |
BASS: ±8dB at 100Hz
TREBLE: ±8dB at 10kHz |
| Power supply |
230V~(50Hz) / 115V~(60Hz) |
| Power consumption |
330W
90W (under no signal), 0.5W (at standby) |
| External dimensions |
440(W) x 178(H) x 454(D) mm
front side knob of 20mm and rear side terminal
of 27mm included in depth |
| Net weight |
22.5kg (main unit) |
| Accessories |
Remote control (RA-17A)
Power cable |
Speaker terminal
Supported Y-lug terminal
dimension |
Width of part a: 15mm or less
Width of part b: 8mm or more
* Connection may not be performed depending on the shape of the Y-lug terminal.
|
