The new Astell & Kern SE300 is the first A&K player with true analog sound with R2R DAC and Class A and AB amplification.It features two new firsts for an Astell&Kern music player: an R2R DAC and Class A/AB dual amplifiers. The A&futura line of AK music players continues to innovate in new and exciting ways. Bringing new technology and sonic possibilities to your music, the new SE300 is a music player like no other.
The new SE300 combines the DAC and the AMP sections for the first time during an initial design phase. The SE300 comes equipped with an R-2R DAC instead of a Sigma Delta DAC that is most commonly used in other portable music players. The R-2R DAC, also known as a ladder DAC, arranges resistors in a ladder form and offers natural yet dynamic Hi-Fi sounds. It is extremely technical and difficult to execute as it requires complex refined resistor units and hard-to-manage current controls.
Despite these technical challenges and after several years of development and much trial and error, Astell&Kern has managed to overcome this and create a new analog sound. In the process, AK has meticulously selected each of the 96 ultra-precision resistors and finalized the R2R DAC technology. The SE300 takes us one step closer to realizing real analog sound from a digital source, and it's the result of a long journey taken by Astell&Kern with uncompromising craftsmanship to find the ultimate sound solution.
The SE300 Includes A Case.
SPECIFICATIONS:
-
Model
SE300
-
Body Color
Platinum Silver
-
Body Material
Aluminum and Stainless Steel
-
Display
5.46inch HD 1080 x 1920 touch screen
-
Supported Audio Formats
WAV, FLAC, WMA, MP3, OGG, APE, AAC, ALAC, AIFF, DFF, DSF
-
Sample rate
PCM : 8kHz ~ 384kHz (8/16/24/32bits per Sample)
DSD : DSD64(1bit 2.8MHz), Stereo / DSD128(1bit 5.6MHz), Stereo / DSD256(1bit 11.2MHz), Stereo
-
Output Level
[Normal] Unbalanced 2Vrms │ Balanced 4Vrms (Condition No Load)
[High] Unbalanced 3Vrms │ Balanced 6Vrms (Condition No Load)
-
CPU
Quad-core
-
DAC
Full Discrete R-2R
-
Decoding
Support up to 32bit / 384kHz playback
-
Input
USB Type-C input (for charging & PC & MAC)
-
Outputs
Unbalanced Out (3.5mm), Optical Out(3.5mm)
Balanced Out (2.5mm, only 4-pole supported | 4.4m, only 5-pole supported)
-
Wi-Fi
802.11 a/b/g/n/ac (2.4/5GHz)
-
Bluetooth
V5.0 (A2DP, AVRCP, Qualcomm® aptX™ HD, LDAC)
-
Dimensions
3.01” (76.45mm)[W] x 5.49” (139.45mm)[H] x 0.69” (17.6mm)[D]
-
Weight
About 11.18oz (317g)
-
Feature Enhancements
Firmware upgrade supported (OTA)
-
Operating Temperature
0℃ ~ + 40℃ (32℉~ 104℉)
AUDIO PERFORMANCE
-
Frequency Response
±0.038dB (Condition : 20Hz~20kHz) Unbalanced │Balanced
±0.45dB (Condition : 20Hz~70kHz) Unbalanced │Balanced
-
S/N
114dB @ 1kHz, Unbalanced │ 115dB @ 1kHz, Balanced (Normal Gain)
115dB @ 1kHz, Unbalanced │ 115dB @ 1kHz, Balanced (High Gain)
-
Crosstalk
-135dB @ 1kHz, Unbalanced │ -144dB @ 1kHz, Balanced
-
THD+N
0.006% @ 1kHz, Unbalanced │ 0.006% @ 1kHz, Balanced
-
IMD SMPTE
0.005% 800Hz 10kHz (4:1) Unbalanced │Balanced
-
Output Impedance
Unbalanced Out 3.5mm (1.3ohm) │ Balanced Out 2.5mm (1.3ohm), 4.4mm(1.3ohm)
CLOCK SOURCE
-
Clock Jitter
25pS (Typ)
-
Reference Clock Jitter
500 Femto Seconds
STORAGE CAPACITY
-
Built-in Memory
256GB [NAND]
-
External Memory
microSD x1 (Max. 1TB)
BATTERY
-
Capacity
5,050mAh 3.8V Li-Polymer
-
Charge Time
about 3.5hours (9V 1.67A Charging)
-
Playback Time
about 12hours (Standard : FLAC, 16bit, 44.1kHz, Vol.50, LCD Off, Normal Gain)
SUPPORTED OS
