DAC |
ESS ES9028Q2M |
Preamp Mode |
Yes |
StreamMagic Version |
Gen 4 |
Display Screen |
4.76" IPS TFT - 1280 x 569 |
USB Drive Input |
1 x USB 2.0 |
S/PDIF TOSLINK Input |
1 |
S/PDIF Coaxial Input |
1 |
Asynchronous USB Input |
1 |
Bluetooth |
5.0 with aptX HD |
HDMI ARC Input |
1 (eARC compatible) |
Analogue RCA Outputs |
1 Pair |
S/PDIF Output |
1 |
TOSLink Output |
1 |
Balanced XLR Output |
1 Pair |
S/PDIF TOSLink Optical |
16/24bit 32-96kHz PCM, DoP64 S/PDIF |
S/PDIF Coaxial |
16/24bit 32-192kHz PCM, DoP64 |
HDMI eARC |
PCM up to 24bit/192kHz |
Local USB Media |
PCM up to 32-bit 768kHz, DSD up to x512 File system support FAT32, NTFS, Ext2/3/4, ExFAT |
USB Audio |
PCM up to 32-bit 768kHz, DSD up to x512 |
Bluetooth |
5.0 A2DP/AVRCP supporting SBC, aptX and aptX HD codecs |
UPnP |
PCM up to 32bit/768kHz |
Internet Radio |
Yes |
Tidal Connect |
Yes |
Spotify Connect |
Yes |
Qobuz |
Yes |
Deezer |
Yes |
Amazon Music |
Yes (via Google Cast) |
Google Cast |
Yes |
AirPlay 2 |
Yes |
Roon Ready |
Yes |
Audio Formats |
ALAC, WAV, FLAC, AIFF, DSD (x512), WMA, MP3, AAC, HE AAC, AAC+, OGG Vorbis |
Ethernet |
IEEE 802.3, 10 Base-T or 100 Base-T |
WI-FI |
IEEE 802.11 a/b/g/n/ac (2.4GHz / 5GHz) |
RS232 Control |
Yes |
THD @ 1kHz 0dBFs |
< 0.0005 % |
Frequency Response |
20Hz-20kHz +/- 0.1dB |
Crosstalk @1kHz |
< -120dB |
Signal to Noise Ratio (Ref 1W) |
> 120dBr |
Max Power Consumption |
30W |
Standby Power Consumption |
Network Standby: >2W ; Eco mode: <0.5W |
Dimensions (W x H x D) |
430 x 90 x 305mm |
Weight |
4.1kg |
In the box |
Mains lead, control bus cable, antenna x2, quick start guide, safety sheet, registration card |
