| Frequency Range (+/-3 dB) [Hz] |
47 - 30,000 |
| Sensitivity (2,83 V/1 m) [dB] |
88 |
| Nominal Impedance [ohms] |
4 |
| Maximum SPL [dB] |
109 |
| Recommended Amplifier Power [W] |
30 - 150 |
| Crossover Frequency [Hz] |
2,400 / 14,000 |
| Crossover Principle |
2 + ½-way |
| Hybrid tweeter module, Super high freq. driver, Quantity |
1 x 17 x 45 mm |
| Hybrid tweeter module, Super high freq. driver, Diaphragm type |
Ribbon
|
| Hybrid tweeter module, High frequency driver, Quantity |
1 x 29 mm |
| Hybrid tweeter module, High frequency driver Diaphragm type |
Soft Textile Dome
|
| Midrange driver, Quantity |
1 x 6 1/2" |
| Midrange driver, Diaphragm type |
Wood Fibre Cone
|
| Enclosure type |
Bass Reflex
|
| Bass Reflex Tuning Frequency [Hz] |
44 |
| Connection Input |
Single Wire
|
| Magnetic Shielding |
No |
| Recommended Placement |
Shelf or stand
Centre / Soundbar
|
| Recommended Distance From Wall [cm] |
0 - 30 |
| Dimensions With Base (HxWxD) [mm] |
201 x 435 x 312 |
| Accessories Included |
Manual
Rubber Feet
|
| Weight [kg] |
9.2 |
