Name: Fiio M17 Flagship Portable Music Player ON SALE
Brand: Fiio
SKU: 42973077078257
Price: 2,099.00 CAD
Availability: InStock

Fiio

$2,099.00

Compare at $2,499.00

You save 16% $400.00

Free Shipping In Canada

Quantity

On Sale. Open Box. Not A Return. One Only.

K19 Is Also On Sale.

No Discounts Possible With This Product.

Affirm Cannot Be Used With This Product.

The desktop-class M17 is an entirely new chapter of FiiO digital audio players. Its desktop-grade DAC, amplification, power supply, etc. give it the output power and sound quality to rival and perhaps even surpass highly-regarded desktop systems - but in a portable package. Let the M17 redefine what is possible with portable audio players.

Desktop-class amplification also plays an important role in the M17. FiiO and THX jointly developed the exclusive THX AAA-788+, an upgraded version of the original op-amp. Compared to the original, output power is increased by 225% up to 3000mW per channel with a lower output impedance – allowing it more effortlessly power all kinds of headphones.

The left and right audio channels each contain a desktop-class, 8-channel ES9038PRO flagship DAC. This means that each audio channel has 8 parallel outputs summed together for superior resolution and minimal distortion for extremely pure audio reproduction.

SPECIFICATIONS:
Name/Model	M17	Hardware solution	Soc: Snapdragon 660, DAC: ES9038PRO2, Amp: THX AAA-788+, Bluetooth: QCC5124, USB: XMOS XUF208, NDK Femtosecond crystal oscillator2
User Interface	Android/Pure Music/USB DAC/Bluetooth Receiver/AirPlay mode	Color	Black
Size	≈156.488.528mm	Volume control type	≈610g
Display	5.99 inches (1080*2160) incell fully fit screen	Volume control type	Knob or button control
RAM	4GB	ROM	64GB/≈46GB
TF card	Single TF card slot, theoretically support up to 2TB	Gain control	Low/medium/high/Over-ear headphone mode/Enhanced over-ear headphone mode (when connected to DC)
Channel balance	L20~R20（0.5dB/level）	Recommended headphone impedance	16~150Ω (SE output)/16~300Ω (BAL output)
Connections:
Buttons	Physical button + analog potentiometer volume knob + HOLD lock switch + BAT/DC switch + touch screen	USB	Two-way TYPE C USB3.0（Charging/Data transmisson)，USB HOST Type-C USB2.0
Phone Output	3.5mm single-ended+6.35mm single-ended+2.5mm balanced+4.4mm balanced	Line out（LO)	3.5 mm port（shared PO）
COAX Output	"RCA socket (coaxial decoding, coaxial output multiplexing) Coaxial decoding supports up to 192kHz-24bit/DSD64 Coaxial output supports up to 384kHz-24bit/DSD128"	Balanced Line out	4.4 mm port（shared 4.4mm balanced PO）
FEATURES:
WiFi	2.4GHz/5GHz，DLNA、AirPlay、WiFi music transfer	Bluetooth transmitter（5.0）	SBC/AAC/aptX/aptX HD/LDAC
Bluetooth receiver（5.0）	SBC/AAC/aptX/aptX Low Latency/aptX HD/aptX Adaptive/LDAC	FiiO Link	WiFi and Bluetooth control (Android), Bluetooth control (IOS)
MQA	MQA 8x unfold	All to DSD	Yes
Double click to wakeup	Not supported, to be upgraded	In-vehicle mode	Would power on/off automatically when vehicle engine starts/stops
Sampling Rate Supported Up to	Local playback: up to 384kHz-32bit/DSD256	USB Audio	384kHz-32bit/DSD256 ( D2P/DOP)
Sampling Rate Supported Up to	USB DAC: up to 768kHz-32bit/DSD512	USB Audio	768kHz-32bit/DSD512 ( Native)
Power-off timers	sleep/Idle poweroff	Equalizer	10-band EQ (±12dB), 8 presets+custom preset, custom EQ supported
Firmware Upgrade	Supports via zip file + TF card + OTA	Navigation control	Gesture control/2-Bottom navigation/3-Bottom navigation
POWER SUPPLY:
Power supply	Supports QC3.0, QC4.0 and PD2.0 and PD3.0 fast charge, POWER IN DC 12V	Battery capacity	9200mAh
Charging time	about 4.5h (QC fast charge)	Standby time	＞1000h
Battery life and test conditions
3.5mm headphone output：＞10h
Volume	76	Gain	L
Screen	Off	Test File	MP3 44.1kHz/16bit
EQ	Off	Load	32Ω
2.5mm+4.4mm balanced output：＞8h
Volume	65	Gain	L
Screen	Off	Test File	MP3 44.1kHz/16bit
EQ	Off	Load	32Ω
AUDIO:
PO output parameters（Over-ear headphone mode）
Output power	≥740mW（16Ω / THD+N＜1%)	Output impedance	≤1Ω（32Ω）
Output power	≥500mW（32Ω /THD+N＜1%)	Crosstalk	≥75dB（1kHz/32Ω）
Output power	≥63mW（300Ω / THD+N＜1%)	THD+N	≤0.0007%（1kHz/32Ω）
Noise floor	≤3.5μV（dbA）	SNR	≥120dB（dbA）
Frequency response	5Hz~80kHz（-3dB）	Peak output voltage	11.3 Vp-p
PO output parameters（Enhanced over-ear headphone mode）
Output power	≥1.4W（16Ω / THD+N＜1%)	Output impedance	≤1Ω（32Ω）
Output power	≥1.1W（32Ω /THD+N＜1%)	Crosstalk	≥75dB（1kHz/32Ω）
Output power	≥126mW（300Ω / THD+N＜1%)	THD+N	≤0.0009%（1kHz/32Ω）
Noise floor	≤3.5μV（dbA）	SNR	≥122dB（dbA）
Frequency response	5Hz~80kHz（-3dB）	Peak output voltage	16.9 Vp-p
LO output parameters
THD+N	≤0.0006%（1kHz/10kΩ）	SNR	≥120dB（dbA）
Crosstalk	≥103dB（1kHz/10kΩ）	Noise floor	≤2μV（dbA）
Frequency response	5Hz~80kHz（-3dB）	LO Output Level	1.9V（1kHz/10kΩ）
PO balanced output parameters（Over-ear headphone mode）
Output power	≥1.5W（16Ω / THD+N＜1%)	Output impedance	≤2Ω（32Ω）
Output power	≥3W（32Ω /THD+N＜1%）	THD+N	≤0.0007%（1kHz/32Ω）
Output power	≥250mW（300Ω /THD+N＜1%)	Crosstalk	≥108dB（1kHz/32Ω）
Noise floor	≤7μV（dbA）	SNR	≥121dB（dbA）
Frequency response	5Hz~80kHz（-3dB）	Peak output voltage	19.7 Vp-p
PO balanced output parameters（Enhanced over-ear headphone mode）
Output power	≥1.5W（16Ω / THD+N＜1%)	Output impedance	≤2Ω（32Ω）
Output power	≥3W（32Ω /THD+N＜1%）	THD+N	≤0.0009%（1kHz/32Ω）
Output power	≥500mW（300Ω /THD+N＜1%)	Crosstalk	≥108dB（1kHz/32Ω）
Noise floor	≤7μV（dbA）	SNR	≥121dB（dbA）
Frequency response	5Hz~80kHz（-3dB）	Peak output voltage	27.7 Vp-p
LO balanced output parameters（dbA）
THD+N	≤0.0006%（1kHz/10kΩ）	SNR	≥122dB（dbA）
Crosstalk	≥105dB（1kHz/10kΩ）	Noise floor	≤3μV（dbA）
Frequency response	5Hz~80kHz（-3dB）	LO Output Level	3.9V（1kHz/10kΩ）
File format support
Lossless	DSD：DSD64/128/256（“.iso”,“.dsf”,“.dff”），DST iSO DXD：352.8kHz/24bit APE FAST/High/Normal：384kHz/24bit（MAX） APE Extra High：192kHz/24bit（MAX） APE Insane：96kHz/24bit（MAX） Apple Lossless：384kHz/32bit（MAX） AIFF：384kHz/32bit（MAX） FLAC：384kHz/32bit（MAX） WAV：384kHz/32bit（MAX） WMA LOSSLESS：96kHz/24bit（MAX）
Lossy	MP3，OGG，WMA，AAC, etc.
