The JL Audio Dominion d108 Subwoofer combines a state-of-the-art Subwoofer and an advanced Class D amplifier to deliver unmatched performance and value for a wide variety of compact applications. This subwoofer reproduces powerful low-frequency events with stunning impact and precision, produces higher output levels with reduced distortion, as well as improved dynamic tracking and resolution. As a result, Dominion® subwoofers are capable of peak-to-peak excursions well in excess of 2.5-inches (63 mm - d108), and 2.7 inches (68 mm – d110), without distress or audible distortion.
Specifications:
| Unbalanced Inputs |
Stereo or Mono (two RCA jacks) |
| Balanced Inputs |
N/A |
| Speaker/High-Level Inputs |
Stereo or Mono (removeable plug) |
| Input Grounding |
Isolated or Grounded |
| Input Modes |
N/A |
| Level Control |
Variable, from full mute to +15dB over reference gain |
| Filter Mode(s) |
Low-Pass |
| Filter Slope(s) |
24 dB/octave |
| Filter Frequency Range |
25 Hz - 130 Hz |
| Filter Defeat Function |
Yes |
| Polarity |
0 or 180 degrees |
| Phase |
Variable, 0- 280 degrees, referenced to 80 Hz |
| Extreme Low Frequency (E.L.F.) Trim |
N/A |
| Line Outputs |
N/A |
| Output to Slave |
N/A |
| Calibration Mode |
N/A |
| Enclosure Type |
Sealed |
| Enclosure Finish |
Black Ash |
| Frequency Response (Anechoic) |
31 - 112 Hz (±1.5dB)
-3 dB at 29 Hz / 119 Hz
-10 dB at 21 Hz / 143 Hz |
| Effective Piston Area (Sd) |
32.18 sq in / 0.0208 sq m |
| Effective Displacement |
80 cu in / 1.3 L |
| Amplifier Power |
500 W RMS short-term |
| Power Mode |
Automatic (Signal-Sensing) |
| Light Modes |
N/A |
| Width (W) |
10 in / 254 mm |
| Height (H) |
11.37 in / 289 mm |
| Depth (D) |
13.23 in / 336 mm |
| Net Weight |
26.4 lb / 12 kg |
