The JL Audio Dominion d110 Subwoofer combines a state-of-the-art Subwoofer and an advanced Class D amplifier to deliver unmatched performance and value for a wide variety of compact applications. This subwoofer reproduces powerful low-frequency events with stunning impact and precision, produces higher output levels with reduced distortion, as well as improved dynamic tracking and resolution. As a result, Dominion® subwoofers are capable of peak-to-peak excursions well in excess of 2.5-inches (63 mm - d108), and 2.7 inches (68 mm – d110), without distress or audible distortion.
Specifications:
| Unbalanced Inputs |
Stereo or Mono (two RCA jacks) |
| Balanced Inputs |
N/A |
| Speaker/High-Level Inputs |
Stereo or Mono (removeable plug) |
| Input Grounding |
Isolated or Grounded |
| Input Modes |
N/A |
| Level Control |
Variable, from full mute to +15dB over reference gain |
| Filter Mode(s) |
Low-Pass |
| Filter Slope(s) |
24 dB/octave |
| Filter Frequency Range |
25 Hz - 130 Hz |
| Filter Defeat Function |
Yes |
| Polarity |
0 or 180 degrees |
| Phase |
Variable, 0- 280 degrees, referenced to 80 Hz |
| Extreme Low Frequency (E.L.F.) Trim |
N/A |
| Line Outputs |
N/A |
| Output to Slave |
N/A |
| Calibration Mode |
N/A |
| Enclosure Type |
Sealed |
| Enclosure Finish |
Black Ash |
| Frequency Response (Anechoic) |
27 - 111 Hz (±1.5dB)
-3 dB at 25 Hz / 118 Hz
-10 dB at 21 Hz / 143 Hz |
| Effective Piston Area (Sd) |
48.71 sq in / 0.0314 sq m |
| Effective Displacement |
127 cu in / 2.08 L |
| Amplifier Power |
750 W RMS short-term |
| Power Mode |
Automatic (Signal-Sensing) |
| Light Modes |
N/A |
| Width (W) |
12 in / 305 mm |
| Height (H) |
13.4 in / 340 mm |
| Depth (D) |
15.86 in / 403 mm |
| Net Weight |
38.2 lb / 17.3 kg |
