The new KEF Ci200QS's thin bezel and narrow rim allow for flawless integration into your wall or ceiling. This product features KEF's Uni-Q driver, which spreads sound over a wider area enabling you to use less speakers. These two features alone combine to make the Ci200QS perfect for any space.
The Q Series features KEF's sophisticated 'sit anywhere' Uni-Q driver array, which places the tweeter in the acoustic centre of the bass/midrange cone, this allows both the tweeter and woofer to act as a single point source that disperses the sound widely and evenly throughout the room. Together with the discreet Ultra Thin Bezel (UTB) design, offering the slimmest possible visible rim around the speaker, the Ci Q Series range gives you tremendous freedom to position the speakers where you please.
Features:
UTB™ Ultra Thin Bezel
200mm (8.0in.) Uni-Q driver array
25mm (1.0in.) Aluminium dome tweeter and 'tangerine' waveguide
Gold plated spring loaded binding posts
PRICED PER PAIR.
Specifications QR (Round):
Sensitivity
90dB (2.83V/ 1m)
Frequency Response
35Hz - 34kHz (±6dB) 2pi/open-backed
Drive Units
LF: 200mm (8.0in.)
HF: 25mm (1.0in.)
Recommended Amplifier Power
10 - 150W
Product External Dimension (H X W X D)
Diameter : 289.6mm (11.4in.)
Depth : 109.8mm (4.33in.)
Cut-Out Dimensions (H X W)
Diameter : 240mm (9.45in.)
Mounting Thickness
Ceiling Thickness (Maximum): 37mm (1.46 in.)
Ceiling Thickness (Minimum): 6mm (0.24 in.)
Mounting Depth From Surface
Product only : 103.3mm (4.07in.)
Optional Rough In Frame
RIF200R
Net Weight
2.4 kg (5.28 lbs)
SPECIFICATIONS QS (Square):
Sensitivity
90dB (2.83V/ 1m)
Crossover Frequencies
2.5kHz
Frequency Response
45Hz - 20kHz (±6dB) open-backed
Drive Units
LF: 200mm (8in.)
HF: 25mm (1in.) Uni-Q
Recommended Amplifier Power
10-150W
Product External Dimension (H X W X D)
273 x 273 x 106 mm (10.75 x 10.75 x 4.17 in.)
Cut-Out Dimensions (H X W)
238 x 238 mm (9.37 x 9.37 in.)
Mounting Thickness
Ceiling Thickness (Maximum): 38mm (1.5 in.)
Ceiling Thickness (Minimum): 7mm (0.28 in.)
Mounting Depth From Surface
99.8mm (3.93in.)
Optional Rough In Frame
RIF200S
Optional Rear Enclosure
RNC200S
Net Weight
2.4kg (5.3lbs.)
SPECIFICATIONS QL (Long/Rectangular):
Sensitivity
90dB (2.83V/ 1m)
Crossover Frequencies
2.5kHz
Frequency Response
35Hz - 34kHz (±6dB) open backed
Drive Units
LF: 200mm (8in.)
HF: 25mm (1in.) Uni-Q
Recommended Amplifier Power
10-150W
Product External Dimension (H X W X D)
369 x 273 x 106 mm (14.53 x 10.75 x 4.27 in.)
Cut-Out Dimensions (H X W)
334 x 238 mm (13.15 x 9.37 in.)
Mounting Thickness
Ceiling Thickness (Maximum): 37mm (1.46 in.)
Ceiling Thickness (Minimum): 6mm (0.24 in.)
Mounting Depth From Surface
99.8mm (3.93in.)
Optional Rough In Frame
RIF200L
Optional Rear Enclosure
RNC200L
Net Weight
2.6kg (5.77lbs.)
