SPECIFICATIONS:
Drive units (per speaker)
Uni-Q Driver Array:
HF: 19 mm (0.75 in.) vented aluminium dome with Metamaterial Absorption Technology1 MF: 100 mm (4in.) aluminium cone
Uni-Core Force Cancelling Driver:
LF: 4 x 135 mm (5.25 in.):
Frequency range (-6dB) measured at 85dB/1m
26 Hz - 36 kHz (Depends on EQ settings)
Frequency response (±3dB) measured at 85dB/1m
31 Hz - 24 kHz (Depends on EQ settings)
Amplifier output power (per speaker)
LF: 500W (class D)
MF: 100W (class D)
HF: 100W (class AB)
Wireless streaming features
AirPlay 2
Google Chromecast
ROON Ready
UPnP Compatible
Bluetooth
Streaming services (availability varies by country)
Spotify via Spotify Connect
Tidal via Tidal Connect
Amazon Music
Qobuz
Deezer
QQ Music via QPlay
Internet Radio
Podcast
Input resolution (depends on source resolution)
Network up to 384kHz/24bit
Optical up to 96kHz/24bit
Coaxial up to 192kHz/24bit
HDMI up to 192kHz/24bit
Interspeaker connection
Wireless: all sources resampled to 96kHz/24bit PCM
Wired: all sources resampled to 192kHz/24bit PCM
Supported format (all inputs)
FLAC, WAV, AIFF, ALAC, AAC, WMA, MP3, M4A, LPCM and Ogg Vorbis
Supported format (network)
MQA, DSD
Primary speaker Inputs
HDMI eARC
TOSLINK Optical
Digital Coaxial
Analog RCA
USB Type A (service only)
RJ45 Ethernet (network)
RJ45 Ethernet (interspeaker)
Secondary speaker Inputs
RJ45 Ethernet (interspeaker)
USB Type A (service only, USB audio not supported)
Outputs
RCA Subwoofer output (both primary speaker and secondary speaker)
Wi-Fi network frequency band / standard
IEEE 802.11a/b/g/n/ac IPv4, IPv6
Power consumption
450W (operating power)
<2.0W (standby power)
Weight (per set)
Dimensions (HWD per speaker)
1090 x 212 x 394 mm (42.9 x 8.3 x 15.5 in.) with plinth
1042 x 130 x 321 mm (41.0 x 5.1 x 12.6 in.) without plinth
