Creating one’s own favourite compilation CD-R and CD-RW’s on a CD ripper is becoming ever more popular, and unlike older CD players, the C 568 will easily play these discs, even those encoded with MP3 and WMA compression. Nearly 10 hours of music can be recorded onto one CD-R when using 128kps compression allowing ‘all day’ background music listening. We have also included a number of additional features to make your listening more enjoyable: RANDOM gives the listener a random selection of all tracks on the disc in play, and REPEAT allows repeat playing of either the entire disc or individual tracks. Individual tracks can also be quickly accessed using the SKIP function (Forward and Back), while the SCAN function (Forward and Back) gives listeners the opportunity to reach specific sections of the track.
Specifications:
Key Features
- CD, CD-R and CD-RW Compatible
- USB Input supports external memory and audio rates up to 384kbps
- MP3 and WMA decoding
- NAD CD-8 full function remote control
- Ultra-High Precision Clock Module for lowest jitter
- Wolfson 24 bit Digital to Analogue Converter
- Super High-Speed OPAmps
- Coaxial Digital Output
- Optical Digital Output
- Toroid Power supply with separate power regulators for analogue and digital sections
- VFL Display with CD text
- Selectable Track, Time and Repeat
- Repeat Mode for single track or entire CD
- Program Play up to 20 tracks
- Random Play
- External IR input
- 12V Trigger input
- <0.5 watt Standby consumption
- Detachable AC cord
General Parameters
- Output level
- Analog: 2.2 ± 0.1 V
Optical: -22.5 ±3.5dBm
Coaxial: 650 ±150mV
- Frequency response
- ±0.3 dB (ref. 0 dB 20 Hz-1 kHz)
±0.5 dB (ref. 0 dB 5 kHz-20 kHz)
- Total harmonic distortion
- <0.01% (ref. 1 kHz, Audio LPF)
- Signal/Noise ratio
- 118 dB (ref. 1 kHz, A-weighted LPF Stop, Pause)
- Channel balance
- ±0.5 dB (ref. 0dB 1kHz)
- Dynamic range
- 95dB
- Channel separation
- >90dB
- De-emphasis
- -3.73 to -5.33 dB (ref. 0dB 1 kHz, 5 kHz)
-8.04 to -10.04 dB (ref. 0dB 1 kHz, 16 kHz)
- Linearity
- ±0.01 dB (ref. 0dB 1 kHz at -3 dB)
±0.02 dB (ref. 0dB 1 kHz at -6 dB)
±0.02 dB (ref. 0dB 1 kHz at -10 dB)
±0.05 dB (ref. 0dB 1 kHz at -20 dB)
±0.15 dB (ref. 0dB 1 kHz at -60 dB)
- Standby power
- <0.5W
USB
- Output level
- 2.2 ± 0.2V
- Frequency response
- ±1dB (ref. 0dB 20Hz – 16kHz)
- Total harmonic distortion
- <0.03% (ref. 0dB 1kHz, Audio LPF)
- Signal/Noise ratio
- 118dB (ref. 0dB 1kHz, A-weighted Pause)
Weight & Dimensions
- Gross Unit Dimensions* (W x H x D)
- 435 x 80 x 306mm
17 1/8 x 3 3/16 x 12 11/16″**
- Net weight
- 4.9kg (10.8lb)
- Shipping weight
- 6.9kg (15.2lb)
