Output:
|
•High |
|
Output Voltage:
|
>2.12mV |
|
Available As Dual Coil Mono:
|
•Yes |
| Type: |
•Fixed Coil / Moving Iron |
| Mount: |
• Standard ½” |
| Stylus: |
• Elliptical Nude, 0.12 mm square |
| Radius of Curvature: |
• 6 x 17 µm |
| Cantilever: |
• Aluminum Alloy |
| Recommended Tracking Force: |
• 2.0 - 2.5 g |
| Effective Tip Mass: |
• 0.55 mg |
| Compliance: |
• 10 µm/mN |
| Frequence Response: |
• 20 - 20,000 Hz ± 2.5 dB |
| Channel Separation @ 1000 Hz: |
• > 26 dB |
| Channel Separation @ 50 - 15,000 Hz: |
• > 20 dB |
| Channel Difference: |
• < 1.6 dB |
| Output Voltage @ 5cm/sec: |
• > 2.12 mV (HIGH) |
| DC Resistance (DCR): |
• 680Ω |
| Coil Inductance per channel: |
• 190 mH |
| Suggested Preamp Gain: |
• 38 - 44 dB |
| Cartridge Weight: |
• 10.25 g |
| Recommended Load Resistance: |
• ≥ 47kΩ |
| Recommended Load Capacitance: |
• n/a
|
