updated to 3rd generation in Sept 2021
-
Compatible with Apple iPhone/iPad, Android devices, Mac and Windows computers, how-to video
-
Class-A balanced headphone amplifier and DAC
-
Up to 1.5w power output (4.4mm balanced)
-
Tubes: 12AU7 / 5963 driver tubes, self-biasing
-
Premium Polytetrafluoroethylene (PTFE) tube sockets
-
ESS SABRE Audiophile DAC up to 24-bit/384kHz PCM, and 128DSD/5.6MHz
-
XMOS xCORE-AUDIO asynchronous USB compatible with PC, Mac, Android and iOS devices
-
High-retention USB connector x 1
-
RCA analog Input x 1
-
4.4mm (5-pole) by Pentaconn by NIPPON DICS balanced headphone output (recommended)
-
6.3mm (1/4”) stereo headphone output
-
Compatible with full-size headphones and IEMs (8–600 Ohms)
-
Frequency response: 10Hz to 46kHz, -3dB
-
Signal to noise ratio: 100 dB
-
Tube preamplifier function (PRE-OUT):
- 4.4mm (5-pole) by Pentaconn by NIPPON DICS balanced pre-out output (recommended)
- 6.3mm (1/4”) stereo pre-out
-
Anodized aluminum chassis, available in midnight black or silver [coming soon]
-
External dimensions with glass: 5.25" (H) x 4.8" (W) x 6" (D)
-
Weight: 8.5 lbs.(3.9kg)
-
Internal linear power supply
-
Global voltage (100v–240v) without converter
-
Designed and assembled in New York, USA
-
Three-year limited warranty
