| Number of Channels |
7.2 |
| Amplifier Power |
100 W (8 ohms, 0.06% THD) |
| Video Upscaling |
Up to 4K |
| 3D Capable |
Information Not Available |
| Dolby Sound Format Compatibility |
Dolby Atmos, Dolby Atmos Height Virtualization Technology, Dolby TrueHD, Dolby Digital Plus, Dolby Surround |
| DTS Sound Format Compatibility |
DTS:X, DTS-HD Master Audio |
| HDMI Input(s) |
7 |
| HDMI Output(s) |
1 |
| Composite Video Input(s) |
None |
| Composite Video Output(s) |
None |
| Component Video Input(s) |
None |
| Component Video Output(s) |
None |
| Analog Audio Input(s) (RCA Inputs) |
4 |
| Analog Audio Output(s) (RCA Outputs) |
None |
| Pre-amp Input / Phono Input |
Yes |
| Pre-amp Output(s) |
2.2-ch |
| Optical Digital Audio Input(s) |
1 |
| Coaxial Digital Audio Input(s) |
1 |
| Coaxial Digital Audio Output(s) |
None |
| iPod Connectivity |
Via Airplay |
| Headphone / Line Output(s) |
1 |
| USB Port(s) |
1 |
| Ethernet Port(s) |
1 |
| Radio Tuner |
AM/FM |
| Streaming Service Compatibility / Connectivity |
Yes |
| DAC Type |
32-bit / 384kHz (Burr-Brown) |
| Multi-Zone |
2 Zones |
| Wi-Fi / Bluetooth Connectivity |
Wi-Fi + Bluetooth |
| HDMI-CEC |
Yes |
| IR Extender Port |
1 In / 1 Out |
| ARC (HDMI Audio Return Channel) |
eARC support |
| 12V Trigger |
Yes |
| DLNA Certified |
Information Not Available |
| HDCP Compliance |
HDCP 2.3 |
